SAE Quick coupling
·
XU3-GR
SAE 24.00mm - 30° - Ø25X2mm - SCR UREA
— Specifications
GeometryStraight
Working temp.-40 / 120 °C
Pressure5–7 bar
AdBlue temp.-40 / 70 °C
Total length60 mm
StandardSAE
FamilySAE Quick coupling
CategorySAE 24 mm Quick Connectors
— Interfaces · 2
Female 1/2
Quick Coupling Connector
Inner Ø24 mm
Outer Ø40.5 mm
StandardSAE
Fitting dim.24 mm
Min.23.85 mm
Max.24.15 mm
Male 2/2
Fir-tree
Inner Ø18.73 mm
Outer Ø26.4 mm
Fitting materialPlastic pipe
Fitting dim.21 mm
Tube min.20.8 mm
Tube max.21.2 mm
— Solutions · Applications
Electrical/Fuel Cell Powertrain
Thermal management systemLow pressure gases/vapours
Internal combustion Engines
Fuel SystemLow pressure gases/vapours managementLubrication SystemThermal management SystemDiesel Exhaust Fluid (AdBlueTM) System
Autonomous Driving
Fluid/Air Washer System
Electrical Fast Charging
Cooling System
Data Centers
Cooling System
Green Energy Production
Air/fluid actuators
